序號 | 型 號 |
流量Q (m 3 /h) |
揚(yáng)程 (m) |
轉(zhuǎn)速 (r/min) |
效率 (%) |
軸功率 (kW) |
功率 (kW) |
1 | 25FB-16 | 3.6 | 16 | 2900 | 33 | 0.48 | 0.75 |
2 | 25FB-16A | 3.25 | 13 | 34 | 0.34 | 0.75 | |
3 | 25FB-25 | 3.6 | 25 | 30 | 0.82 | 1.5 | |
4 | 25FB-25A | 3.25 | 20 | 31 | 0.57 | 1.1 | |
5 | 25FB-40 | 3.6 | 40 | 23 | 1.71 | 2.2 | |
6 | 25FB-40A | 3.25 | 32.7 | 24 | 1.21 | 1.5 | |
7 | 40FB-16 | 7.2 | 16 | 44 | 0.71 | 1.5 | |
8 | 40FB-16A | 6.55 | 13 | 46.7 | 0.5 | 1.1 | |
9 | 40FB-20 | 7.2 | 20 | 42 | 0.93 | 1.5 | |
10 | 40FB-25 | 7.2 | 25 | 39 | 1.26 | 2.2 | |
11 | 40FB-25A | 6.55 | 21 | 40 | 0.94 | 1.5 | |
12 | 40FB-40 | 7.2 | 40 | 32 | 2.45 | 3 | |
13 | 40FB-40A | 6.55 | 32.5 | 33.5 | 1.73 | 3 | |
14 | 40FB-63 | 7.2 | 63 | 22.8 | 5.42 | 7.5 | |
15 | 40FB-63A | 6.55 | 55 | 27 | 3.73 | 5.5 | |
16 | 50FB-16 | 14.4 | 16 | 16 | 1.09 | 2.2 | |
17 | 50FB-16A | 13.1 | 13 | 57 | 0.81 | 1.5 | |
18 | 50FB-25 | 14.4 | 25 | 52 | 1.83 | 4 | |
19 | 50FB-25A | 13.1 | 20.5 | 51.5 | 1.42 | 3 | |
20 | 50FB-40 | 14.4 | 40 | 46 | 3.32 | 5.5 | |
21 | 50FB-40A | 13.1 | 33 | 45 | 2.62 | 5.5 | |
22 | 50FB-63 | 14.4 | 63 | 39 | 6.16 | 11 | |
23 | 50FB-63A | 13.1 | 54.5 | 38 | 5.24 | 11 | |
24 | 65FB-16 | 28.8 | 16 | 62 | 2.08 | 4 | |
25 | 65FB-25 | 28.8 | 25 | 62 | 3.16 | 5.5 | |
26 | 65FB-25A | 26.2 | 20.5 | 62 | 2.36 | 4 | |
27 | 65FB-30 | 28.8 | 30 | 60.5 | 3.89 | 7.5 | |
28 | 65FB-30A | 26.2 | 24 | 62 | 2.76 | 5.5 | |
29 | 65FB-40 | 28.8 | 40 | 57.5 | 5.46 | 7.5 | |
30 | 65FB-40A | 26.2 | 32.5 | 58 | 4 | 5.5 | |
31 | 65FB-64 | 28.8 | 64 | 52.5 | 9.57 | 15 | |
32 | 65FB-64A | 26.2 | 55 | 51.5 | 7.83 | 11 | |
33 | 80FB-15 | 54.4 | 15 | 69 | 3.2 | 5.5 | |
34 | 80FB-15A | 49.1 | 11.5 | 69 | 2.23 | 4 | |
35 | 80FB-24 | 54.4 | 24 | 68 | 5.19 | 7.5 | |
36 | 80FB-24A | 49.1 | 20 | 68 | 3.94 | 5.5 | |
37 | 80FB-38 | 54.4 | 38 | 66.5 | 8.41 | 15 | |
38 | 80FB-38A | 49.1 | 31.5 | 66.5 | 6.34 | 11 | |
39 | 80FB-60 | 54.4 | 60 | 62.8 | 14.06 | 22 | |
40 | 80FB-60A | 49.1 | 52.5 | 62.5 | 11.56 | 18.5 | |
41 | 100FB-23 | 100.8 | 23 | 73 | 8.65 | 15 | |
42 | 100FB-23A | 91.8 | 19 | 73 | 6.51 | 11 | |
43 | 100FB-37 | 100.8 | 37 | 73 | 13.92 | 22 | |
44 | 100FB-37A | 91.8 | 31 | 70.5 | 11 | 15 | |
45 | 100FB-57 | 100.8 | 57 | 70.5 | 22.2 | 37 | |
46 | 100FB-57A | 91.8 | 51.5 | 70.5 | 18.77 | 30 | |
47 | 150FB-22 | 190.8 | 22 | 77 | 14.86 | 22 | |
48 | 150FB-22A | 173.5 | 17.5 | 78 | 10.6 | 18.5 | |
49 | 150FB-35 | 190.8 | 35 | 76 | 23.94 | 37 | |
50 | 150FB-35A | 173.5 | 28 | 76 | 17.42 | 30 | |
51 | 150FB-56 | 190.8 | 56 | 76 | 38.31 | 55 | |
52 | 150FB-56A | 173.5 | 48 | 76 | 30.67 | 45 |
