型 號
CQB |
流 量
Q
(m3/h)
|
揚(yáng)程 H
(m)
|
汽蝕余量(MPSH)r
(m)
|
轉(zhuǎn) 速
n
(r/min)
|
軸功率(KW)
|
效 率(%)
|
配帶電機(jī)功率KW
|
||
介質(zhì)密度g/cm3
|
|||||||||
<1
|
<1.3
|
<1.84
|
|||||||
CQB32-20-125
|
1.9
3.2
3.8
|
20
20
18.5
|
5.0
|
2900
|
0.49
0.58
0.62
|
23
30
31
|
Y801-2YB0.75
|
Y802-2YB1.1
|
Y90S-2YB1.5
|
CQB32-20-160
|
1.9
3.2
3.8
|
34
32
29
|
3.5
|
2900
|
0.84
0.99
1.03
|
21
28
29
|
Y802-2YB1.1
|
Y90S-2YB1.5
|
Y90L-2YB2.2
|
CQB40-25-105
|
3.8
6.3
7.5
|
13
12.5
11
|
6.0
|
2900
|
0.42
0.55
0.56
|
32
39
40
|
Y801-2 YB0.75
|
Y802-2YB1.1
|
Y90S-2YB1.5
|
CQB40-25-125
|
3.8
6.3
7.5
|
22
20
18.5
|
5.0
|
2900
|
0.81
0.98
1.05
|
28
35
36
|
Y802-2YB1.1
|
Y90L-2YB2.2
|
Y100L-2YB3.0
|
CQB40-25-160
|
3.8
6.3
7.5
|
34
32
29
|
3.5
|
2900
|
1.41
1.72
1.79
|
25
32
33
|
Y90L-2YB2.2
|
Y100L-2YB3.0
|
Y112M-2YB4.0
|
CQB40-25-200
|
3.8
6.3
7.5
|
52.5
50
48
|
3.5
|
2900
|
3.02
3.43
3.77
|
18
25
26
|
Y112M-2YB4.0
|
Y132S1-2YB1.1
|
Y132S2-2YB7.5
|
CQB50-40-85
|
7.5
12.5
15
|
9
8
7.5
|
3.5
3.5
4.0
|
2900
|
0.46
0.56
0.61
|
40
49
50
|
Y801-2YB0.75
|
Y802-2YB1.1
|
Y90S-2YB1.5
|
CQB50-32-105
|
7.5
12.5
15
|
13
12.5
11
|
3.5
3.5
4.0
|
2900
|
0.76
0.91
0.94
|
35
47
48
|
Y802-2YB1.1
|
Y90S-2YB1.5
|
Y90L-2YB2.2
|
CQB50-32-125
|
7.5
12.5
15
|
22
20
18.5
|
3.5
3.5
4.0
|
2900
|
1.49
1.62
1.63
|
30
42
43
|
Y90L-2YB2.2
|
Y100L-2YB3.0
|
Y112M-2YB4.0
|
CQB50-32-160
|
7.5
12.5
15
|
34
32
29
|
3.5
3.5
4.0
|
2900
|
2.48
2.79
2.96
|
28
39
40
|
Y100L-2YB3.0
|
Y112M-2YB4.0
|
Y132S1-2YB5.5
|
CQB50-32-200
|
7.5
12.5
15
|
52.5
50
48
|
3.5
3.5
4.0
|
2900
|
5.10
5.49
6.13
|
21
31
32
|
Y132S2-2YB7.5
|
Y132S2-2YB7.5
|
Y160M1-2YB11
|
CQB50-32-250
|
7.5
12.5
15
|
82
80
78.5
|
3.5
3.5
4.0
|
2900
|
9.57
10.89
13.32
|
17.5
25
26
|
Y160M2-2YB15
|
Y160L-2YB18.5
|
Y180M-2YB22
|
CQB65-50-125
|
15
25
30
|
22
20
18.5
|
3.5
3.5
4.0
|
2900
|
2.25
2.67
2.91
|
40
51
52
|
Y100L-2YB3.0
|
Y112M-2YB4.0
|
Y132S1-2YB5.5
|
CQB65-50-160
|
15
25
30
|
34
32
29.5
|
3.5
3.5
4.0
|
2900
|
4.34
5.07
5.48
|
32
43
44
|
Y132S1-2YB5.5
|
Y132S2-2YB7.5
|
Y160M1-2YB11
|
CQB65-40-200
|
15
25
30
|
53
50
47
|
3.5
3.5
4.0
|
2900
|
8.66
9.20
10.1
|
25
37
38
|
Y160M1-2YB11
|
Y160M2-2YB15
|
Y160L-2YB18.5
|
CQB65-40-250
|
15
25
30
|
82
80
78.5
|
3.5
3.5
4.0
|
2900
|
13.4
14.72
16.88
|
25
37
38
|
Y160L-2YB18.5
|
Y180M-2YB22
|
Y200L1-2YB30
|
CQB80-65-125
|
30
50
60
|
22.5
20
18
|
4.0
4.0
4.5
|
2900
|
4.48
5.24
5.55
|
41
52
53
|
Y132S1-2YB5.5
|
Y132S2-2YB7.5
|
Y160M1-2YB11
|
CQB80-65-160
|
30
50
60
|
34
32
29
|
4.0
4.0
4.5
|
2900
|
7.72
9.08
9.67
|
36
48
49
|
Y160M1-2YB11
|
Y160M2-2YB15
|
Y160L-2YB18.5
|
CQB80-50-200
|
30
50
60
|
53
50
47
|
4.0
4.0
4.5
|
2900
|
12.03
14.80
16.34
|
36
46
47
|
Y160L-2YB18.5
|
Y180M-2YB22
|
Y200L1-2YB30
|
CQB80-50-250
|
30
50
60
|
84
80
75
|
4.0
4.0
4.5
|
2900
|
19.06
23.68
26.07
|
36
46
47
|
Y200L1-2YB30
|
Y200L2-2YB37
|
Y225M-2YB45
|
CQB100-80-125
|
60
100
120
|
23
20
16.5
|
4.0
4.0
4.5
|
2900
|
8.35
9.73
9.46
|
45
56
57
|
Y160M1-2YB11
|
Y160M2-2YB15
|
Y160L-2YB18.5
|
CQB100-80-160
|
60
100
120
|
35
32
28
|
4.0
4.0
4.5
|
2900
|
12.43
15.85
16.34
|
46
55
56
|
Y160L-2YB18.5
|
Y180M-2YB22
|
Y200L1-2YB30
|
CQB100-65-200
|
60
100
120
|
54
50
47
|
4.0
4.0
4.5
|
2900
|
21.01
25.69
28.44
|
42
53
56
|
Y200L1-2YB30
|
Y200L2-2YB37
|
Y225M-2YB45
|
CQB100-65-250
|
60
100
120
|
86
80
74.5
|
4.0
4.0
4.5
|
2900
|
37.98
45.39
49.69
|
37
48
49
|
Y225M-2YB45
|
Y250M-2YB55
|
Y280S-2YB75
|
